Note: It cannot be used in HP printers.
Model |
| |
Working Width | 1800mm | |
Voltage | 24V | |
Motor Power | 36W | |
Maximum Diameter Of Hosting Media | Ø260mm | |
Packing Size | 2600 x 380 x 380mm | |
Gross Weight | 35kg | |
![](http://www.optim-tec.com/qfy-content/uploads/2023/06/ee90385fc78207fcb081fba3d200f0c3.png)
• Automated take-up system
• Inductive tension system
• Novel double-track structure
• Automatic seitch: Automatic rolling according to induction of the tension bar.
• Regarding the medium core, 2 inches(Φ48mm-Φ53mm)and 3inches(Φ75mm-Φ80mm) are available.
• Specialized universal linking slab, apply to any printers.
![](http://www.optim-tec.com/qfy-content/uploads/2023/06/006e787691b56b5891544effb900337a.png)
• Automatic rewinding, unattended production
• Tension control system could expands its application range for outdoor and indoor printing material,fabric with no elasticity and fiber material
• Bear the weight of 40-50KG
• Fixed directly without drilling holes in the machine
• Extend lifespan of motors
![](http://www.optim-tec.com/qfy-content/uploads/2023/06/9930b33444cd786bc051b07f6a2c9fa4.png)
• Automatic system without workman that help you save cost, save space
• More widely applicable range, Aqueous & Eco solvent & Sublimation printing materials.
There is no trouble of taking up no elasticity fabric materials such as format canvas and cloth banners.
![](http://www.optim-tec.com/qfy-content/uploads/2023/06/32063654622676bce00acd291c329946.png)
To be used with:
Mimaki / Roland Large Format
![](http://www.optim-tec.com/qfy-content/uploads/2023/06/9092aab145bf103bf4a9631743da7196.png)
![Automatic Media Take-up Roller for Mutoh VJ1604 details](http://www.optim-tec.com/qfy-content/uploads/2023/06/2517bc8f1579963e2a6bbf551603b0b2.png)
![](http://www.optim-tec.com/qfy-content/uploads/2023/06/8793d2068724eb6e4fa69ad9c084c3d0.png)
![Automatic Media Take-up Roller for Mutoh VJ1604 usage](http://www.optim-tec.com/qfy-content/uploads/2023/06/12ea1f43dfa5fb8b5ef5a1001c9b33f9.png)
1.Open box, and separate the connecting plate and the take-up system. | 2. Mount the connecting plate. |
![Automatic Media Take-up Roller for Mutoh VJ1604 usage](http://www.optim-tec.com/qfy-content/uploads/2023/06/19fb8d3c684deaedb9c3674d31f41a20.png)
3. Loosen tension bar and set screws. | 4. Put the take-up system on the connecting platete. |
![Automatic Media Take-up Roller for Mutoh VJ1604 usage](http://www.optim-tec.com/qfy-content/uploads/2023/06/d588007a8673f373506acb5aa953a0f5.png)
5. Tighten the screws to settle take-up system. | 6. Adjust the position of dynamic roll axis on take-up system and fasten the axis |
![Automatic Media Take-up Roller for Mutoh VJ1604 usage](http://www.optim-tec.com/qfy-content/uploads/2023/06/0e36ad12e7e17caa094983de6d854b77.png)
7. Connect the power transformer (12V) to power supply. | 8. Load the paper roll. |
![Automatic Media Take-up Roller for Mutoh VJ1604 usage](http://www.optim-tec.com/qfy-content/uploads/2023/06/aafd9501dc1a969b9b6b4febdc531b20.png)
9. Attach take-up system to the printed material. | 10. Adjust the tension and the switch. |
![Automatic Media Take-up Roller for Mutoh VJ1604 usage](http://www.optim-tec.com/qfy-content/uploads/2023/06/59620ee25fe9a4492ea7c98d0036c845.png)
Packing List:
![]() | Take up system | 1set |
![]() | Power Cable and 24V DC Power Supply | 1set |
![]() | Hexagon Wrench | 1pc |
![]() | User Manual | 1pc |
![](http://www.optim-tec.com/qfy-content/uploads/2023/06/b59ff7d03d6f77b0cee4c53f7d8af09c.png)
![Automatic Media Take-up Roller for Mutoh VJ1604 application](http://www.optim-tec.com/qfy-content/uploads/2023/06/d621d7951716c4a6f4d952fc32c716c0.png)
For any questions,please message us via ebay.
