Description:
The four-piece energy HT1600 plastic welding kit from Weldy includes professional hot air equipment for welding thermoplastics such as HDPE, PP and PVC (vinyl). The kit includes the robust Weldy energy HT1600 heat gun, a 4 mm speed welding nozzle (article no. 146.740), a 5 mm tube nozzle (article no. 130.632) as well as a pair of spare carbon brushes for the blower motor (article no. 125.810). The temperature of the easy-to-use Weldy HT1600 heat gun can be continuously adjusted from 40°C (104°F) to 700°C (1292°F).
This practical Weldy kit contains everything needed for plastic welding tanks and containers. It is suitable for plastic repairs, welding plastic pipes and tanks, sealing pond liners, building and repairing plastic boats made from HDPE, etc. The robust energy HT1600 plastic welding kit from Weldy is also excellent for beginners and is available at a very fair price.
Specification:
VOLTAGE | 120V / 230V |
|---|---|
FREQUENCY | 50/60 Hz; 60 Hz |
POWER | 1600W |
TEMPERATURE | 40 - 700 °C / 104.0 - 1292.0 °F |
TEMPERATURE SETTING STEPLESS | Yes |
AIRFLOW (20°C) | 240 l/min / 8.47 cfm |
STEPLESS AIR VOLUME ADJUSTMENT | No |
STATIC PRESSURE | 2600 Pa / 0.37 psi |
ECO-MODE | No |
DISPLAY | No |
E-DRIVE | No |
OUTDOOR USE | Yes |
NOZZLE CONNECTION Ø | 31.5 mm / 1.25 in |
LENGTH | 346.0 mm / 13.62 in |
DEVICE DIAMETER | 101 mm / 3.97 in |
HANDLE DIAMETER | 59 mm / 2.32 in |
WEIGHT | 0.99 kg / 2.18 lb |
POWER CABLE LENGTH | 3.0 m / 9.84 ft |
PLUG | UK, 3 poles, 13A; US, 2 poles, 15A, polarized; EU, 2 poles, 16A; |
NOISE EMISSION LEVEL | 67 dB (A) |
APPROVALS | CE; KC |
PROTECTION CLASS | II |
Highlights:
- Basic plastic welding kit
- 4 mm speed welding nozzle included
- Spare carbon brushes for blower motor included
- Delivered with durable storage case
- 5 mm pipe nozzle included in the kit
- Plastic welding kit for tank construction
- Robust Weldy heat gun
- Good quality at a fair price
- Heat gun with stepless temperature adjustment
Application:
The hot torch plastic welding gun tool is widey used for welding PVC film and TPO film, for short and small format materials. Also, this hot blast plastic welding gun welder is suitable for waterproof canvas, tarpaulins, celling cloth, etc
